The Harvia Vega Compact 1900 is a 1.9 kW wall-mounted electric sauna heater for rooms of 70–106 adjusted cubic feet running on 120VAC 1PH. It takes 29 lb of 5-10cm sauna stones (sold separately). Controls are built into the heater, so no separate control unit is required.
Vega Compact exists for rooms that every other heater is too big for: closet conversions, one-person cabins, barrel sauna ends and pre-fab kits under 175 cu ft. It measures 11 × 11 in and hangs on the wall with built-in controls, so the entire install is a bracket and a circuit.
- Switches can be installed on the right or left side of the heater
- Smallest footprint in the Harvia range at 11 × 11 in
- Runs on a dedicated 120 V circuit — no 240 V feed required
- Built-in controls — no separate control unit required
Sauna Heater, Installation and Operation Manual
Controls are built into this heater. No separate control unit is needed, and none can be added.
These are not included with the heater. You need them before the sauna will run.
Sauna Stones29 lb — Harvia specifies 1 × 44 lb boxes of Harvia AC3000. Never run the unit empty. Electrical
A dedicated hardwired circuit, installed by a licensed electrician.
| Harvia Part Number | HCBU19U1UL |
| Power Output | 1.9 kW |
| Sauna Room Volume | 70–106 adjusted cu ft |
| Stone Capacity | 29 lbs (13.2 kg) |
| Recommended Stones | Harvia AC3000 |
| Maximum Temperature | 194 °F (90 °C) |
| Color / Finish | Stainless Steel |
| Material | Steel |
| Dimensions (W × D × H) | 11" (279mm) × 11" (279mm) × 21" (533mm) |
| Weight (Empty) | 15.4 lbs (7 kg) |
| Weight Loaded with Stones | approx. 44 lbs |
| Installation | Wall Mount |
| Controls | Built into the heater |
| Certification | CE, EAC, ETL |
| Warranty | 2 years (consumer use, +1 year if registered with Harvia); 2 years (commercial use) |
| Ships | Parcel |
| Made In | Finland |
| Part Number | Power | Voltage | Phase | Rated Amps | Line Fuse |
|---|---|---|---|---|---|
| HCBU19U1UL | 1.9 kW | 120VAC | 1PH | 15.9 A | See manual |
Hardwired on a dedicated circuit. Not a plug-in appliance. Who Installs It
A licensed electrician sizes the breaker and conductors from the nameplate and installation manual under the current NEC. Line Fuse
Harvia's published line-fuse value for this model does not agree with its own rated amperage, so we have not printed it. Size from the nameplate.
The Harvia Vega Compact 1900 is rated for 70–106 adjusted cubic feet.
Adjusted cubic feet = width × depth × height in feet, plus 45 cu ft for every square foot of glass, tile, concrete or stone, plus 15 cu ft for every square foot of exposed log wall. A 6 × 7 ft room with a 7 ft ceiling is 294 raw cu ft — add a full-glass door and it becomes 834. Always size to the adjusted number.
| Model | Output | Room Volume | Stones | Rated Amps |
|---|---|---|---|---|
| Vega Compact 1900 | 1.9 kW | 70–106 cu ft | 29 lbs | 15.9 |
| Vega Compact 3500 | 3.5 kW | 70–175 cu ft | 29 lbs | — |
- Mount to the clearances given in the installation manual. The temperature sensor goes on the wall above the heater, at the height the manual specifies.
- Load the stones loosely by hand, largest at the bottom, so air moves freely between them. Never run the heater with an empty or tightly packed stone space.
- Pour small ladlefuls of clean water onto the hot stones only — never onto the body, elements or controls. Mix any scented oil into the bucket first.
- Re-stack the stones once a year and replace any that have cracked or crumbled.
- Stones ship separately on their own freight because of the weight.
Does the Harvia Vega Compact 1900 include a control unit?
Yes. The thermostat and timer are built into the heater body, so there is nothing else to buy to run it. The trade-off is that you cannot start it from outside the room or from a phone.
Can the Harvia Vega Compact 1900 be plugged into a normal outlet?
No. It is a hardwired appliance on its own dedicated circuit, rated at 15.9 A. A licensed electrician sizes the breaker and conductors from the nameplate and installation manual.
How long does the Harvia Vega Compact 1900 take to heat up?
Harvia does not publish a figure. A correctly sized, well-insulated room is usually ready in 30 to 60 minutes. Consistently longer than an hour normally means the heater is undersized for the room's adjusted cubic feet.
