The Harvia Fenix FX30 is a Wi-Fi digital sauna control unit for Harvia heaters up to 11 kW, supplied for 240V single-phase or 208V three-phase. The panel mounts outside the hot room. It is sold separately from the heater and is required for heaters supplied without built-in controls.
The Fenix FX30 carries the same load rating as the Xenio CX30 — 7 kW on one 240V supply wire, 11 kW on two, 10.5 kW at 208V three-phase — in the glass-panel Fenix format.
- Controls the sauna heater, lighting, and ventilation
- Intelligent user interface that is precise and easy
- High-quality glass screen control panel
- Learns with AI and adapts to the performance of your sauna heater
Control Panel, Temperature Sensor, Please Note: If the sensor comes with the heater, you must install per the instructions in the heater manual., Power Unit, Data Cable, Installation Materials, Installation and Operation Manual
A Harvia sauna heater supplied without built-in controls, and a dedicated circuit installed by a licensed electrician.
| Harvia Part Number | FX30-U1-U3-XC |
| Maximum Load | 7 kW on one 240V supply wire; 11 kW on two 240V supply wires; 10.5 kW on 208V three-phase |
| Voltage | 240/208 |
| Phase | 1/3 |
| Temperature Range | 194°F |
| Maximum Session Time | 60 MINUTES |
| Mountable Inside the Sauna | NO |
| Hardwired | YES |
| Color / Finish | Black |
| Material | Plastic |
| Dimensions | 3.4"W (86mm) x 1"D (25mm)x 4.4"H (111mm) |
| Weight | 7 lbs |
| Installation | Wall-Mount |
| Certification | ETL |
| Warranty | 2 years (consumer use, +1 year if registered with Harvia); 2 years (commercial use) |
| Ships | Parcel |
| Made In | Finland |
The Fenix FX30 carries the same load rating as its Xenio equivalent, so it drives the same heaters.
Cilindro (Electric)Harvia Cilindro PC60E Club
Harvia Club K10G Spirit
Harvia Spirit SP60E Virta
Harvia Virta HL60E
Heaters with controls built into the body — Harvia KIP-B, The Wall, Vega Compact and the Cilindro PC range — do not take a separate control unit.
- The power unit is hardwired between the supply and the heater by a licensed electrician; the panel and the temperature sensor are wired back to it to the lengths the installation manual gives.
- The temperature sensor mounts inside the hot room, on the wall above the heater, at the height the manual specifies. Sensor position changes how the room behaves more than any setting on the panel does.
Which Harvia heaters does the Fenix FX30 work with?
It carries the same load rating as its Xenio equivalent, so it drives the Cilindro (Electric), Club, Spirit and Virta series. Heaters with controls built into the body do not take a separate control unit.
Can the Fenix FX30 be mounted inside the sauna?
No. This panel mounts outside the hot room. Only the temperature sensor goes inside, on the wall above the heater.
Does the Fenix FX30 need an electrician?
Yes. The power unit is hardwired between the supply and the heater, and the sensor and data cable have to be run to the manual's specification. In most US jurisdictions that is work a licensed electrician has to do and an inspector signs off.
