The Bromic Eclipse Smart-Heat Pendant is a 2900W ceiling-hung electric infrared patio heater with an integrated dimmable LED light. It warms up to 121 sq. ft., hangs from the included 24in twin ceiling pole, comes in 240V or 208V, and pairs with the Bromic Affinity Eclipse control (sold separately) for app-based heat and light control.
At a Glance- Heat output: 2900W electric infrared, 3 heat levels (33%, 66%, 100%)
- Heat coverage: Up to 121 sq. ft.
- Power: 240V (12.1A) or 208V (14A), hardwired
- Lighting: Dimmable 13W LED
- Mounting: 24in twin ceiling pole included, 5 other poles optional
- Controls: Sold separately: Affinity Eclipse control
- Weather rating: IP54
- Finish: Matte Black
The 27.6in circular head hangs level over a table, bar or lounge and replaces a pendant light, giving heat and a soft glow from one fixture. Swap to a straight, curved or wall pole to suit your ceiling height.
Three heat settings for up to 121 sq. ft. under pergolas and covered patios. Integrated LED Lighting
Dimmable LED adds ambient light. Twin Pole Included
24in twin ceiling pole keeps the head level and balanced. Six Mounting Options
8in, 24in and 48in straight, 24in curved, twin and 61in wall poles. Affinity Eclipse Ready
Control heat and light from the Bromic Heating app with an Affinity Eclipse control (sold separately). IP54 Rated
Matte black head with a radial ceramic screen.
| Model | Eclipse Smart-Heat™ Electric Pendant |
| Fuel Type | Electric |
| Color | Matte Black |
| Weight | 30 lbs |
| Model Numbers | BH0920001-1 (240V) • BH0920003 (208V) |
| Wattage | 2900W |
| Heat Settings | 33% • 66% • 100% |
| Heat Area | 121 ft² |
| Rated Current | 12.1A (240V) • 14A (208V) |
| Heater Head | 27.6" × 27.6" × 4.4" |
| Minimum Floor Clearance | Wall 96" | Ceiling 96" |
| Light Output | 13W LED, dimmable |
| Ingress Rating | IP54 |
| Approval Certification | SGS / NA SGSNA/21/GZ/00074 |
| Control Options | Sold separately: Affinity Eclipse 1 Channel • Affinity Eclipse 5 Channel (3-phase) • Manual Wall Switch |
| Warranty | 3 years (from date of purchase, original owner) |
| Mounting Option | Image |
|---|---|
| 8in Straight Ceiling Pole |  |
| 24in Straight Ceiling Pole |  |
| 24in Curved Ceiling Pole |  |
| 48in Straight Ceiling Pole |  |
| 61in Wall Mount Pole |  |
This Eclipse heater ships with a 24in twin ceiling pole and integrated LED lighting. Add an alternate pole for your ceiling height or a wall install, and control heat and light with a Bromic Affinity Eclipse control through the free Bromic Heating app. The control is not included and is sold separately.
How much area does the Bromic Eclipse Pendant cover?
Up to 121 square feet from its 2900W infrared element, with three heat settings: 33%, 66% and 100%.
What voltage do I need?
Choose 240V (BH0920001-1, 12.1A) or 208V (BH0920003, 14A) to match your building's supply. Bromic requires installation by a licensed electrician to local code.
What mounting options are available?
It ships with a 24in twin ceiling pole. Optional 8in, 24in and 48in straight poles, a 24in curved pole and a 61in wall mount pole let you match your ceiling height or mount it on a wall.
How do I control the heat and light?
Controls are sold separately. Add the Affinity Eclipse 1 Channel control (BH8380051) to adjust heat and light separately from the Bromic Heating app, with timers and schedules. The 5 Channel version runs several heaters on 3-phase power.
How high does it need to hang?
Bromic requires the heater head to be at least 8ft (96") above the floor on both ceiling and wall installs, with 3.3ft clear in front of it.
Can it be used indoors?
Yes. It is IP54 rated for outdoor use, and Bromic approves the Eclipse for indoor commercial and residential spaces as well.
Electric patio heaters must be installed in accordance with local electrical codes. Improper installation may result in property damage or injury. Professional installation is recommended.
