Bromic Platinum Smart-Heat Gas Heater – 500 Series Wall or Ceiling Mounted Outdoor Patio Heater
Choose options
- Description
- Key Features
- Product Specifications
- Heat Coverage Area
- Product Video
- Product Dimensions
- Downloads
- Safety Information
- Proposition 65 Warning
- Installation & Controls
The Bromic Platinum Smart-Heat Gas Heater – 500 Series combines elegant design with high-performance radiant heating for larger residential patios and outdoor commercial spaces. Featuring Bromic’s signature ceramic fascia in a sleek black or stainless finish, this wall or ceiling mounted gas heater delivers directional warmth deep into the outdoor living space while producing a soft red glow.
Designed for covered patios, outdoor dining areas, and hospitality environments, the 500 Series produces up to 39,800 BTUs of heat output and can warm areas up to 215 square feet. Available in both Natural Gas and Liquid Propane configurations, this premium gas heater is built to perform in wind conditions up to 12 mph, helping keep outdoor spaces comfortable even in challenging conditions.
This heater is compatible with Bromic Affinity Smart On/Off controls for convenient operation and is also compatible with a manual wall switch setup for fixed installations.
Powerful radiant gas heating designed for larger outdoor patios and seating areas. Elegant Platinum Design
Sleek ceramic fascia and refined styling for premium outdoor living environments. Wide Heat Coverage
Heats outdoor areas up to 215 sq. ft. for comfortable outdoor entertaining. Natural Gas or Propane
Available in both NG and LP configurations to suit different installation requirements. Wall or Ceiling Mount
Designed for fixed installation with flexible wall-mounted or ceiling-mounted placement. Affinity Control Compatible
Compatible with Bromic Affinity On/Off controls for convenient outdoor heating control.
| Series | Platinum Smart-Heat™ Gas 500 Series |
| Fuel Type | Natural Gas or Liquid Propane |
| Heat Output | 39,800 BTU |
| Heat Coverage | Up to 215 sq. ft. |
| Finish Options | Black or Stainless |
| Model Options | BH0110004-1 (LP) • BH0110003-1 (NG) |
| Electrical Connection | 110V / 2A |
| Dimensions | 29.8" W × 16.6" H |
| Weight | 44 lbs |
| Minimum Floor Clearance | 96" |
| Approval Certification | Intertek 4009079 |
| Control Options | Affinity On/Off • Manual Wall Switch |
Gas patio heaters must be installed in accordance with local gas and electrical codes. Improper installation may result in fire, injury, or property damage. Professional installation is recommended.
This gas heater comes with a wall-mount bracket and can also be ceiling-mounted using an optional ceiling pole, sized to your ceiling height. For low-clearance ceilings, add a heat deflector to reduce the required overhead clearance. Gas heaters are on/off only — control yours with a Bromic On/Off control and wireless app, or a manual wall switch. (For dimmable output, see our electric heaters.)
